Enermax Cooler ETS T40 W
Deskripsi
Enermax Cooler ETS T40 W
Information
- Side-Flow
CPU cooler with 12cm PWM fan and four 6mm high-performance heat pipes. - New! Thermal Conductive Coating*
Innovative, thermal-conductive coating for an efficient heat dissipation and higher cooling performance.
* only ETS T40 BK & ETS T40 W - Adjustable Peak Speed (APS)*
Multi-purpose fan for easy customisation according to the system requirements. With a small switch at the back, the peak speed can be changed in three steps. The fan therefore offers three various RPM ranges: Silent Mode / Performance Mode / Overclock Mode.
* only ETS-T40-W - Optimized Air Stream Conduction
Unmatched thermal resistance of 0,085°C/W (ETS-T40-TB: 0,09°C/W) due to optimized air stream conduction: Stack Effect Flow (SEF, patented), Vortex Generator Flow (VGF, patented) und Vacuum Effect Flow (VEF). - Heat Pipe Direct Touch (patented)
The heat pipes directly rest on the CPU, so that the CPU heat can be dissipated effectively without additional resistance. - Universal bracket for Intel® and AMD®
User-friendly CPU cooler mounting supports all Intel and AMD CPU: Intel® 775/1150/1155/1156/1366/2011 and AMD® AM2/AM2+/AM3/AM3+/FM1/FM2. - Twister Bearing
Smooth running and persistent silent 12cm PWM fan with patented Twister Bearing Technology (min. 100,000 hours MTBF). - Bright Colours*
Eye-catching and bright colours thanks to patented circular LED light. Enermax LED fans shine many times brighter than ordinary LED fans.
* only ETS T40 BK - Click Mechanism
Fan with detachable blades for easy cleaning from dust. - Expandable Cooling System
Second fan bracket included in the delivery for cooling system upgrade with one additional 12cm fan. - Effective Vibration Reduction
Adhesive rubber strips to reduce vibrations of the installed fan. - High Conductive Thermal Grease
Tube with Dow-Corning® thermal grease (TC-5121) for best thermal conduction between CPU and heat sink.
Detail
Specifications
Models | ETS-T40-W | ETS-T40-BK | ETS-T40-TB |
Compatible Sockets | Intel® LGA 775/1150/1155/1156/1366/2011 AMD® AM2/AM2+/AM3/AM3+/FM1/FM2 |
||
Overall Dimensions (mm) | L 139 x W 93 x H 160 | ||
Heat Sink Dimensions (mm) | L 139 x W 70 x H 160 | ||
Heat Sink Coating | white | black | no coating |
Number / Thickness of Heat Pipes | 4 x Ø 6mm | ||
Thermal Resistance (°C/W) | 0.085 | 0.09 | |
Weight (without fan) | 610g | ||
Material | Copper Heat Pipes / Aluminium Fins | ||
Thermal Grease | Dow Corning® TC-5121 | ||
Fan | |||
Fan Model | Cluster Advance | T.B.Apollish | T.B.Silence |
Fan Dimensions (mm) | 120 x 120 x 25 | ||
Bearing Type | Twister Bearing Technology (patented) | ||
Fan Speed (RPM) | 800 – 1,500/1,800/2,200* | 800 – 1,800 | 800 – 1,800 |
Air Flow (m3/h) | 63.9 – 121.1/147.30/180.0* | 56.51 – 129.09 | 63.83 – 147.30 |
Air Flow (CFM) | 37.57 – 71.3/86.70/105.9* | 33.26 – 75.98 | 37.57 – 86.70 |
Static Pressure (mm-H2O) | 0.7 – 1.7/2.4/3.6* | 0.97 – 2.28 | 0.72 – 2.41 |
Noise Level (dB(A)) | 17 – 24/28/31* | 16 – 26 | 10 – 21 |
Rated Voltage (V) | 12 | ||
MTBF | 100,000 hours | ||
LED | 4x white LED | Patented circular LED light with 12 blue diodes |
none |
Fan connector | 4 pin PWM | ||
Fan Mounting | Metal brackets |
* ETS-T40-W with three APS Modes: Silent Mode / Performance Mode / Overclock Mode.
Dealer Information
ETS-T40-W | ETS-T40-BK | ETS-T40-TB | |
EAN Code | 4713157732828 | 4713157732811 | 4713157731616 |
